Chromalox Fan Forced Unit Heater HVH-07-43-30
Final pricing and shipping details will be determined during the Expert Check process
Category:
Air Heaters
Big Chief is an authorized Chromalox distributor and supplies the Chromalox Fan Forced Unit Heater HVH-07-43-30. The Chromalox HVH self-contained blower heater provides quiet, reliable, fan-forced heat for all types of commercial and industrial applications. Optional wall or ceiling swivel mounting brackets help direct airflow exactly where it is needed. Heavy-duty construction affords long, dependable service, while its two-tone gray polyester powder coat finish makes an attractive appearance. The hallmark of the HVH blower heater is its versatility. It can provide vertical or horizontal airflow and can be mounted on walls or ceilings.
Brand: Chromalox
More about Chromalox Fan Forced Unit Heater HVH-07-43-30
Features and specifications of the Chromalox Horizontal or Vertical Discharge Fan Forced Unit Heater:
- 8,900 - 170,600 Btuh
- Field Convertible - Combination 208/240V and 1 or 3 phase operation through 10 kW.
- Linear Thermal Cutouts open the control circuit and disconnect power to the heating elements if overheating occurs. Automatic Reset allows the control circuit to reclose and restore power when temperature returns to normal.
- Vertical or Horizontal Airflow
- 208, 240, 277, 480, and 600 volt
- 2.6 - 50 kW
- Integral 24V Control Transformer is standard on 480V models and eliminates the need for an external control source( 120V is optional).
- CSA Certified to US and Canadian Standards
- CE Certified to European Standards
- Wall or Ceiling Mounted Configurations
- 1 or 3 phase
- Heavy Duty Magnetic Contactors are standard on all models except 2.6 thru 5 kW single phase models, except for 480V models.
| Name: | Chromalox Fan Forced Unit Heater HVH-07-43-30 |
|---|---|
| Part Number: | HVH-07-43-30-219299 |
| Manufacturer: | Chromalox |
| Air Flow f3 /min (m3 /hr): | 850 (1444) |
| Air Speed ft/min (m/min): | 1040 (317.0) |
| Amps: | 9.9 |
| Ckt & Phase: | 1, 3 |
| Control Voltage: | 24 |
| HP: | Contact us for details |
| Lead Time: | Usually Ships in 3-5 Business Days (expedited shipping may be available please contact us at 1-800-835-4328 for more information) |
| Phase (Motor): | 3 |
| Product Line: | HVH Unit Heater |
| RPM: | 1725 |
| Volts: | 480 |
| Volts (Motor): | 480 |
| kW: | 7.5 |
